TrailMaster Cheetah 6 Kids GoKart

$1,899.00

SKU: TM-CHEETAH-6 Category: Tags: , Brand:

Description

The Cheetah 6 from TrailMaster is a super easy-to-ride gokart perfectly sized for kids to rip around the trails on afternoon adventures! Powered by a 163cc single-cylinder engine paired to an automatic CVT (Continuously Variable Transmission) with Reverse, kids will have no trouble taking the wheel of the Cheetah go-cart and getting rolling with no need to shift gears or operate a clutch.

The Cheetah 6 gokart for kids includes both an electric starter and backup pull starter. The Cheetah features a front seat with a 4-point safety harness that’s adjustable from 28 to 32 inches pedal-to-seat so it can be a good fit for a number of different heights. This buggy also features rack-and-pinion steering, LED headlights, remote start, a speed governor, and a parking break. Several colors.

Specifications:

Model TrailMaster Cheetah 6
Engine single cylinder, 4 stroke, air-cooled
Displacement 163cc
Transmission Automatic CVT w/Reverse
Shift Gear Hand Shift
Final Drive Chain
Climbing Ability 12 degrees
Max Power 3.2kW/3600rpm
Max Torque 10.8N.m/2800rpm
Max Speed 24 MPH
Bore x Stroke 2.67x1.77 inches
Starting System Electric / Pull
Ignition CDI
Battery 12V/10Ah
Fuel Capacity 1 gal.
Brakes (Front/Rear) NA / Hydraulic Disc
Tires (Front/Rear) 145/70-6 / 16x6-8
Suspension (Front/Rear) Double A-arm / Swing-arm
Max Load 180 lbs.
Wheelbase 43.7 inches
Seat Height 14.2 inches
Min Ground Clearance 3.6 inches
Net Weight 264 lbs.
Gross Weight 308 lbs.
Dimensions (LxWxH) 63x36x50 inches
Shipping Dimensions (LxWxH) 60x32x21 inches

Additional information

Weight 308 lbs
Dimensions 60 × 32 × 21 in
Color

Blue, Red, Yellow
