TrailMaster Cheetah 300EX GoKart

$5,599.00

SKU: TM-CHEETAH-300EX Category: Tags: , Brand:

Description

TrailMaster’s bringing the heat with their upgrade from the Cheetah 200EX to the 300EX adult gokart, keeping the EFI of the older model now with a bigger 275cc engine! Electronic fuel injection makes cold starts a problem of the past and allows easy starting in all temperatures and weather conditions with no choke or carburetor. The bigger 275cc engine of this Cheetah buggy brings more than enough horsepower to carry light loads on its rear rack as well as a passenger and still hit a max speed of 38 MPH!

Water-cooling cuts down on the heat the engine has to handle during performance off-road riding, extending the life of the engine and reducing maintenance. A CVT (Continuously Variable Transmission) takes out the hassle of shifting and allows you to focus on the fun of riding. The CVT allows buttery-smooth acceleration as well as excellent low-end torque.

Grown-ups will have a blast on the trails with the Cheetah 300EX go-cart’s high-performance engine, four-wheel independent suspension system as well as its powerful front and rear hydraulic disc brakes. This off-road buggy for adults also includes a number of premium features like LED headlights and signals, an LED light bar, a spare tire, a bikini sunshade top, an adjustable drivers seat and steering wheel, and four-point safety seatbelts. Available in your choice of several colors!

  • Engine & Performance: 275cc EFI engine with water cooling, CVT transmission, and max speed of 38 MPH; carries a passenger and light loads on the rear rack.

  • Handling & Safety: Four-wheel independent suspension, front and rear hydraulic disc brakes, adjustable driver seat and steering, and four-point safety seatbelts.

  • Features & Convenience: LED headlights and signals, LED light bar, spare tire, bikini sunshade top, and multiple color options.

Free shipping in the lower 48 states and we ship internationally!

Specifications:

Model TrailMaster Cheetah 300EX
Engine single cylinder, 4 stroke, water-cooled
Displacement 275.6cc
Transmission Automatic CVT w/Reverse
Shift Gear Hand Shift
Final Drive Chain
Max power 13kW/7500rpm
Max torque 22N.m/5000rpm
Max speed 38 MPH
Starting system Electric w/ kill switch
Ignition CDI
Battery 12V/10Ah
Fuel capacity 2.64 gal.
Brakes (Front/Rear) Hydraulic Disc / Hydraulic Disc
Tires (Front/Rear) 22x7-10 / 22x10-10
Suspension (Front/Rear) Dual A-arm / Independent suspension
Max load 500 lbs.
Wheelbase 71 inches
Seat Height 18.5 inches
Min ground clearance 5.9 inches
Features Sunshade top, LED headlight and signals, LED light bar, spare tire, adjustable steering wheel, four-point safety seatbelts
Net Weight 650 lbs.
Gross Weight 750 lbs.
Dimensions (LxWxH) 92.1x55x58.3 inches
Shipping Dimensions (LxWxH) 88x48x25 inches

Additional information

Weight 650 lbs
Dimensions 88 × 48 × 25 in
Color

Blue, Green, Red, White

Checking for Spark

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Checking the CDI

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Battery Prep

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Checking Fuel Flow

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Checking Coil Wires

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Jumping the Solenoid

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Tightening The Chain

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Checking the Tether

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Inflating the Tires

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Locating the VIN

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

What is Lift Gate?

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Shipping Damage

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

www.familygokarts.com logo
TrailMaster Cheetah 300EX GoKart - Red
