TrailMaster XD 125UF Kids Utility ATV

$1,807.99

SKU: TM-XD-125UF Category: Tags: , , , Brand:

Description

If your kids are wanting a powerful ATV to tear up the trails with their friends with the space to bring all their gear along for the ride, look no further than the XD 125UF from Trailmaster! The 125UF really packs a punch with its 125cc 4-stroke, air-cooled engine, bringing quick acceleration and exhilarating speeds. Riding is effortless and fun with a quick-and-easy electric starter and fully automatic transmission with reverse. Parents can rest easy while their kids are out-and-about with a speed limiter and remote kill switch fully in their control. All-terrain knobby tires and hydraulic disc brakes give the 125UF superior handling and stopping power, and front and rear racks let kids carry all their gear on the trails and help their parents out around the yard. comes in a choice of two tone color options!

Specifications:

Model TrailMaster XD 125UF
Engine 4-stroke, single-cylinder, air-cooled
Displacement 125cc
Transmission Automatic
Shift Gear Foot Shift
Final Drive Chain
Max Horsepower 7.6hp
Max Torque 5.16 foot-pounds
Bore x Stroke 52.4x49.5mm
Starting System Electric
Fuel Capacity .24 gal
Brakes (Front/Rear) Drum / Hydraulic Disc
Tires (Front/Rear) 19x7-8 / 18x9.5-8
Suspension (Front/Rear) Independent Dual A-Arm / Mono Swingarm
Wheelbase 33.7 inches
Seat Height 24.4 inches
Min Ground Clearance 5.5 inches
Max Load TBD
Net Weight 216 lbs.
Gross Weight 260 lbs.
Dimensions (LxWxH) 57.7x36.2x36.4 inches
Shipping Dimensions (LxWxH) 48x30x26 inches

Additional information

Weight 280 lbs
Dimensions 48 × 30 × 26 in
Color

Blue, Red, Silver

Checking for Spark

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Checking the CDI

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Connecting The Battery.

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Changing The Oil

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Battery Prep

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Starting The ATV

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Adjusting the Idle

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Adjusting the Speed Limiter

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Checking Fuel Flow

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Checking Coil Wires

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Jumping the Solenoid

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Tightening The Chain

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Checking the Tether

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Setting Toe and Steering

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Inflating the Tires

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Locating the VIN

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

What is Lift Gate?

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.

Shipping Damage

Note: The products shown in these videos may not be identical to the product sold on this page. However, they contain general information that may prove helpful. Viewing them is highly recommended.
